Hawk 1 RIV 1

SFFECO Hawk Series 1 RIV1 is a rapid intervention vehicle and the most demanding model for municipal & industrial fires. It is a compact but reliable firefighting apparatus, specially designed for urban areas where accessibility of big firefighting truck is a challenge. It is the cost efficient way of bringing the fire under control.

SFFECO Hawk Series 1 RIV1 is commonly built on GMC/Ford Chassis



Featuers:

• Rapid Intervention Vehicle
• Built over GMC3500HD / Ford 350HD
• Single Cabin
• Water Tank Capacity is 800 - 1000L
• Foam Tank Capacity is 100L



Water Tank:

The tank is made of corrosion proof 304 type stainless steel sheet 3mm wall thickness and 3 mm base thickness.



Foam Tank:

The tank is made of corrosion proof stainless steel sheet 316L, 3mm wall thickness and 3mm base thickness. The tank is designed to store all known foam compounds in all running condition.



Body:

The body structure is mainly composed of integrated standard section steel bars, mild steel tubes and aluminium sheets, fiber and bended plates.



Fire Pump: Tohatsu VC52AS / VC72AS

• 1300 L/Min at 0.6 MPa (6 bar)
• 1000 L/Min at 0.8 MPa (8 bar)
• 600 L/Min at 1.0 MPa (10 bar)
